Operation Manual / TPL76-C
12 Spare parts / 12.1 Ordering spare parts
© Copyright 2018 . All rights reserved. HZTL2485_EN Revision F April 2018
12 Spare parts
12.1 Ordering spare parts
When making inquiries or ordering spare parts, the following data must
be specified:
¡ Turbocharger type
¡ Serial number (HT……)
¡ Designation and part number
Spare parts can be ordered from an official ABB Turbocharging service
station.
u If different design versions have not been taken into consideration in
this document, please contact an ABB Turbocharging service station.
CAUTION
Storage of spare parts
All spare parts ordered with the turbocharger must be kept complete
and ready for use.
u Parts showing signs of rust should be carefully cleaned and greased.
u Dispose of replaced and unusable parts in a professional and environ-
mentally compatible way.
Required customer spare part set (97070)
The customer spare part set (97070) is required for the work described
in this Operation Manual. These parts are available only as a complete
set.
Quantity Description Part number
1 O-ring 42012
1 Gasket 42041
2 Gasket 42045
2 Hexagon-head screw 42059, 42064
6 Locking plate 56018
6 Stud 56021
6 Hexagon nut 56022
3 Hexagon nut 61037
12 Hexagon-head screw 61044, 61056
17 Verbus Ripp® washer 61051
3 Socket screw 76002
1 O-ring 76040
1 O-ring 77005
1 O-ring 86506
