Operation Manual / TPL76-C
12 Spare parts / 12.2 View of turbocharger with part numbers
© Copyright 2018 . All rights reserved. HZTL2485_EN Revision F April 2018
Part number Description
01 Cartridge group
42012 (in customer spare part set) O-ring
51001 Gas inlet casing
51012 Segment
56001 Nozzle ring
56018 (in customer spare part set) Locking plate
56021 (in customer spare part set) Threaded stud
56022 (in customer spare part set) Nut
61001 Gas outlet casing
61037 (in customer spare part set) Hexagon nut
61044 (in customer spare part set) Hexagon-head screw
61050 (in customer spare part set) Gasket
61051 (in customer spare part set) Verbus Ripp® washer
61056 (in customer spare part set) Hexagon-head screw
61065 Gasket
61066 Blind flange
61067 Hexagon-head screw
63000 Turbine diffuser
68001 Foot at compressor end
68002 Foot at turbine end
68006 Cup spring
68007 Bush
61079 Gasket
74000 Compressor casing external part
76000 Compressor casing internal part
76002 (in customer spare part set) Socket screw
76040 (in customer spare part set) O-ring
76080 Safety segments
77000 Wall insert
77005 (in customer spare part set) O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
Page 133 / 133
