Operation Manual / TPL76-C
7 Removal and installation / 7.2 Removing the turbocharger
© Copyright 2018 . All rights reserved. HZTL2485_EN Revision F April 2018
Version with compressor wheel cooling system
u Dismantle air supply line. (See also chapter entitled Preliminary re-
marks / Layout and functionality)
u Inspect the lifting gear.
u Secure lifting gear to the suspension eyes of the bearing casing and
the turbine-end foot.
u Unplug the cable connector on the speed sensor.
u Unscrew the fixing screws on the feet.
u Lift the turbocharger off the engine and set it down to one side.
WARNING
If the turbocharger is not sufficiently supported or not supported at all
during removal and installation, it may tip over and cause severe injury
to personnel or accidents resulting in fatalities.
u Support the turbocharger at a suitable point.
u Cover the oil connection.
Page 78 / 133
