9.3.6 Transmission data and influences
Direction of action (output signal or pressure in actuator)
Increasing Increasing output signal 0 ... 100 %
Increasing pressure y1 in the actuator
Decreasing Increasing output signal 0 ... 100 %
Decreasing pressure y1 in the actuator
Characteristic deviation < 0.5 %
Tolerance band 0.3 ... 10 %, adjustable
Dead band 0.1 ... 5 %, adjustable
Resolution (A/D conversion) > 16000 steps
Sample rate 20 ms
Influence of ambient
temperature
< 0.5 % for each 10 K
Influence of vibration < ± 1 % to 10 g and 80 Hz
Seismic requirements
Meets requirements of DIN / IEC 68-3-3 Class III for strong and
strongest earthquakes.
Influence of mounting orientation
Not measurable.
Meets the requirements of the following directives
- EMC Directive 2014/30/EU
- EC Directive for CE conformity marking
9.3.7 Environmental capabilities
Ambient temperature
For operation, storage and transport: -40 … 85 °C (-40 ... 185 °F)
When using proximity switches
SJ2-S1N (NO):
-25 … 85 °C (-13 ... 185 °F)
Relative humidity
Operational (with closed housing
and air supply switched on):
95 % (annual average),
condensation permissible
Transport and storage:
75 % (annual average), non-
condensing
9.3.8 Housing
Material / Degree of protection
Aluminum, protection class IP 65 (optional IP 66) / NEMA 4X
Surface / Color
Electrostatic dipping varnish with epoxy resin, stove-hardened. Case
varnished black, RAL 9005, matte, housing cover Pantone 420.
Electrical connections
Screw terminals:
Max. 1.0 mm
2
(AWG 17) for options
Max. 2.5 mm
2
(14 AWG) for bus connector
IMPORTANT (NOTE)
Do not expose the terminals to strain.
Four thread combinations for cable entry and pneumatic
connection
- Cable: thread 1/2-14NPT, air pipe: thread 1/4-18 NPT
- Cable: thread M20 x 1,5, air pipe: thread 1/4-18 NPT
- Cable: thread M20 x 1,5, air pipe: thread G 1/4
- Cable: thread G 1/2, air pipe: thread Rc 1/4
(Optional: With cable gland(s) and pipe plugs if necessary)
Weight
3,0 kg (1,36 lb)
Mounting orientation
Any
Dimensions
See "Dimensions"
