ABEM Terraloc Pro 2
56
Figure 48 Increased graph min value
• Adjusting the graph max (Figure 48)
― Press <CTRL> + <+> to increase the graph max in 10 dB step
― Press <CTRL> + <-> to decrease the graph max in 10 dB step
Figure 49 Increased graph max value
• Adjusting the threshold (Figure 50)
― Press <+> to increase the threshold in 1 dB step
― Press <-> to decrease the threshold in 1 dB step
