EN - 14
6 Putting into operation CAT2
6 Putting into operation
6.1 Fastening the CAT2 to the robot
This chapter describes the assembly of the robot mounts CAT2 and
CAT2 HL. The process steps step 1 to step 5 refer to both robot versions.
Risk of injury due to unexpected start-up.
The following instructions must be adhered to for the entire duration of
maintenance, servicing, mounting, dismounting and repair work:
• Switch off the power supply.
• Close off the compressed air supply.
• Disconnect all electrical connections.
• Please take note of the following instructions:
3 Product description on page EN-8
• The system may only be installed and put into operation by authorized
personnel (in Germany see TRBS 1203).
• Before CAT2 (10)can be mounted, the robot (7)must be moved to the
maintenance position.
• To fasten the CAT2 (10) to the robot (7) a robot flange is required (8). It
must correspond to the hole pattern of the CAT2 (10) and of the
robot (7).
• To fasten the torch (1) to the CAT2 (10) a torch mount is required (2).
This mount depends on the type of torch.
