Abus CFA 1000 - A) Fastening Element; B) Door Lock Actuator; C) Radio Remote Control; System Description

51
8. System description
a) Fastening element
Mountingholes,41mm(screwifrequired)
Woodenscrews(3x20mm
Mountingwrench
b) Door lock actuator
Handwheelformanuallockingandunlockingfrominside
(doorknobfeature)
Smallset-upkeyforsettingandprogrammingwork
”Unlock”key
LCDdisplay
”Lock”key
Slittoopenthebatterycompartment
Battery
compartment
Battery
compartment
cover
c) Radio remote control
Controllamp
Unlockingkey,(right)
Lockingkey(left)
Key”opendoor”
Batterycompartmentcover
Battery compartment (with inserted button cell, plus points
outwards)
Connectorfor
interface„KM300
RI“(optional)
Control-LEDfor
charging(only
whileusing
rechargeable
batterieswith
„KM300RI“)
Connectorforthe
signal(optional)
