b) Assembly of Fastening Element and Door Lock Actuator
- Slacken the fastening screws (at the left
andrightofthedoorlockactuator)forthe
fasteningelement.
- Remove the fastening element from the
doorlockactuator.
- Makesurethatthenutsremaininthefasten-
ingelement.
- Placethefasteningelementontotheproject-
ingpartofthecylinderlock.
- Fix the fastening element with thescrew
atthetopand thebottomof thecylinder
lock.
- Ifnecessary,thefasteningelementcanbe
fastenedtothedooradditionallywithtwo
woodenscrews(seearrow).
 However,thedoorleafordoorttingwillbedamagedbythesetwoscrews.
 Fortenantedats,thiscouldleadtoclaimsfordamagesortoretentionofthe
rent deposit.
 Normallythetwolateralscrewsatthetopandbottomofthefasteningelementssufce
forthedoorlockactuatortobefastenedsecurely.
1 2
3 4
