Acer AO725 - Lcd 11.6

Hardware Specifications and Configurations 1-29
LCD 11.6”
Item Specification
Vendor & Model name AUO
B116XW03
Screen Diagonal (mm) 293.8
Active Area (mm) 256.125 x 144.0
Display resolution (pixels) 1366x3 (RGB) x 768
Pixel Pitch (mm) 0.1875 x 0.1875
Typical White Luminance
(cd/m
2
) also called
Brightness
200 typ. (5 points average)
170 min. (5 points average)
Contrast Ratio 500 typ.
Response Time (Optical
Rise Time/Fall Time) msec
8 typ. / 16 max.
Typical Power
Consumption (watt)
2.9 max. (Include Logic and BLU power)
Weight (without inverter) 235 max.
Physical Size (mm) 268.5 (H) x 175 (V) x 3.6 (D) max.
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right)
CR = 10 (Left)
Vertical (Upper)
CR = 10 (Lower)
40 min. / 45 typ.
40 min. / 45 typ.
10 min. / 15 typ.
30 min. / 35 typ.
