Main Unit Disassembly Process 0
Main Unit Disassembly Flowchart 0
Figure 3-20. Main Unit DIsassembly Flowchart
Table 3-7. Screws
Step Screw Quantity Part No.
Bottom case Disassembly M2*6 10 86.RN60U.002
M2*3 Ni 1 86.RY8N5.006
Click pad Disassembly M2*3 Ni 2 86.RY8N5.006
Touchpad Board Disassembly M2*2 Ni 2 86.RY8N5.003
Keyboard Disassembly M2*2 3 86.RY8N5.003
M2*3 Ni 16 86.RY8N5.006
Battery Disassembly M2*3 Ni 1 86.RY8N5.006
Card reader Disassembly M2*3 Ni 2 86.RY8N5.006
LCD module Disassembly M2.5*5 Ni 5 86.B050U.001
Mainboard Module M2*3 Ni 4 86.RY8N5.006
Thermal Module M2*3 Ni 6 86.RY8N5.006
Fan to Bottom case M2.5*5 2 86.B050U.001
Speaker Disassembly M2*2L+4.2MM Ni 4 86.RY8N5.001
Top Case
Click Pad Bracket Keyboard Battery Power Switch Board Card Reader LCD Module
DC-in Bracket
Touch Pad
DC-in Connector
Cables from MB
Main Board
BluetoothThermal Module Speaker
