3-76
Replacing the WLAN Module
0
1.
Insert th
e WLAN module into the
connector
.
Figure 3-124.
WLAN Module
2.
Replace the screw on the WLAN module.
Figure 3-125.
WLAN Module
T
able 3-32.
Screws
Ste
p
Screw
Quantity
Screw T
ype
WLAN Module Assembly
M2*
3 Ni
1
