Acer Aspire M3-581T - Removing the Thermal Module

3-36
Removing the Thermal module 0
1. Disconnect the cable of the fan from Mainboard.
Figure 3-52. Thermal module
2. Remove 6 screws from the thermal module.
Figure 3-53. Thermal module
Table 3-15. Screws
Step Screw Quantity Screw Type
Thermal module Disassembly M2*3 6
