3-30
Remove the card reader 0
1. Remove the two screws from the card reader.
Figure 3-39. Card reader
2. Lift the card reader then remove.
Figure 3-40. Card reader
Table 3-12. Screws
Step Screw Quantity Screw Type
Carder reader Disassembly M2*3 2
