3-14
Removing the WLAN Module 0
1. Disconnect the two cables from the WLAN module.
IMPORTANT:
+
Note the position of the Main (black) and Auxiliary (white) connectors.
Figure 3-12. WLAN Module
2. Remove the screw and ensure the cables are well clear of the module.
Figure 3-13. WLAN Module
Table 3-4. Screws
Step Screw Quantity Screw Type
WLAN Module Disassembly M2*3 1
