3-50
Replacing the LCD Panel 0
1. Connect the LVDS cable to the panel and bond the mylar to secure the connector.
Figure 3-76. LCD Panel
2. Place the LCD panel on the LCD cover.
Figure 3-77. LCD Panel
CAUTION:
!
To avoid damage, make sure all cables near the hinge are free and clear to move.
3. Secure the 4 screws on the LCD panel.
