3-63
Replacing the Card reader 0
1. Place the card reader board in the bottom case.
Figure 3-99. card reader
2. Secure the 2 screws on the card reader.
Figure 3-100. Card reader
Table 3-25. Screws
Step Screw Quantity Screw Type
Carder reader Assembly M2*3 2
