Acer Aspire M3-581T - Replacing the Speakers

3-54
Replacing the Speakers 0
1. Place the left speaker assembly into the bottom case.
Figure 3-82. Speakers
2. Secure 2 screws to the left speaker.
Figure 3-83. Speakers
3. Place the right speaker into the bottom case.
Table 3-20. Screws
Step Screw Quantity Screw Type
Speaker Assembly M2*2L+4.2MM
Ni
2
