3-58
2. Replace the 6 screws to secure the thermal module in place.
Figure 3-89. Thermal Module
3. Connect the fan cable to the mainboard.
Figure 3-90. Thermal Module
Table 3-22. Screws
Step Screw Quantity Screw Type.
Thermal module
Disassembly
M2*3 Ni 6
