FRU (Field Replaceable Unit) List 6-5
5 HDD CABLE 50.RY8N5.004
6 ODD SUPER MULTI MODULE ASSY 6M.RY8N5.001
7 SD DUMMY CARD 42.RY8N5.003
8 JM50-1A TOP CASE MODULE
9 HDD HGST 2.5" 5400rpm 500GB
HTS545050A7E380, Jaguar B7,0J23335,
500G/P SATA 8MB LF+HF F/W:DA4837
KH.50007.023
10 HDD COVER
11 Foxconn Wireless LAN Atheros HB97 2x2 BGN
(HM)
NI.23600.072
12 Memory ELPIDA SO-DIMM DDRIII 1600 4GB
EBJ40UG8BBU0-GN-F LF+HF 512*8 38nm
KN.4GB09.005
13 Flash Disk PHISON SSD NAND 20GB
SSE020GTTC0-S51 LF+HF
KN.0200Q.002
14 SCREW M2*6L(K,D4.6) B-ZN #1 NY 86.RY8N5.005
Table 6-1. Main Assembly Exploded Diagram
Item Description Part Number
