6-12 FRU (Field Replaceable Unit) List
BT CABLE 50.RY8N5.002
IO/CARD READER CABLE 50.RY8N5.003
IO/CARD READER CABLE FOR TPM 50.RYKN5.001
HDD CABLE 50.RY8N5.004
LVDS CABLE 50.RY8N5.006
LVDS CABLE EDP
DC-IN CABLE 50.RY8N5.005
CASE/COVER/BRACKET ASSEMBLY
HDD COVER
UPPER CASE ASSY
LOWER CASE ASSY W/ANTENNA , SPEAKER
Table 6-5. FRU list
Category Description P/N
