Chapter 3 93
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Main Screw List
Item Screw Part No.
A M2.5 x L6 86.00E33.736
E M2.5 x L5 86.00F87.735
F M2 x L3 86.00C07.220
LCD MODULE
LCD BEZEL
LEFT HINGE
RIGHT HINGE
Ax8
Ex1
Ex 1
LCD ASSEMBLY
LEFT LCD
BRACKET
Fx4
RIGHT LCD
BRACKET
Fx4
LCD FPC
CABLE
INVERTER BOARD
LCD BACK PANEL
ANTENNAS
LCD MODULE DISASSEMBLY
Ex2
Ex1
VGA
CAMERA
INTERNAL
MICROPHONE
