60 Chapter 3
Removing the Battery Pack
1. Turn base unit over.
2. Slide the battery lock/unlock latch to the unlock position (1).
3. Slide and hold the battery release latch to the release position (2), then remove the battery from the main
unit (3).
Removing the SD dummy card
1. Push the SD dummy card all the way in to eject it (1, 2).
