Chapter 3 69
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Screw List
Screw Part No.
A M2.5 x L6 86.00E33.736
C M2 x L4 86.9A552.4R0
D M2.5 x L5 86.00E74.335
F M2 x L3 86.00C07.220
H M2.5 x L8 86.00E34.738
MAIN UNIT
KEYBOARD
MAIN
BOARD
Cx2
MAIN UNIT DISASSEMBLY
MIDDLE
COVER
LCD MODULE
Hx2Ax2
UPPER CASE
Ax14
LEFT AND RIGHT
SPEAKER MODULE
Cx4
MODEM
BOARD
Cx2
Cx2
CPU/VGA
THERMAL MODULE
CPU
TOUCH PAD BRACKET
ASSEMBLY
Fx2
TOUCH PAD
BRACKET
LAUNCH BOARD
Cx2
HEAT SINK FAN
USB BOARD
C x9 (Cx5 for UMA module)
Fx 2
VGA
BOARD
POWER
BOARD
Fx 1
Dx2
TOUCH PAD
BOARD
FINGERPRINT
BOARD
Fx2
Cx1
