Acer Extensa 5220 Series Service Guide

Index 169
A
AFLASH Utility 51
Antennas 98
Audio 34
B
Battery Pack 60
BIOS 29
package 29
password control 29
ROM size 29
ROM type 29
vendor 29
Version 29
BIOS Supports protocol 29
BIOS Utility 39–51
Navigating 40
Onboard Device Configuration 46
Security 43, 45
System Security 50
Board Layout
Top View
121
brightness
hotkeys
15
C
Cache
controller
30
size 30
caps lock
on indicator
9
CardBus 35
computer
on indicator
9
CPU 73
CPU Fan True Value Table 29
D
DIMM Module 63
Display 4
display
hotkeys
15
E
Error Symptom-to-Spare Part Index 106
Euro 16
External CD-ROM Drive Check 102
External Module Disassembly
Flowchart
59
F
Features 1
Flash Utility 51
fpc cable 96
FRU (Field Replaceable Unit) List 125
H
Hard disk 32
Hard Disk Drive Module 65
HDD 32
Heatsink Module 70
Hibernation mode
hotkey
15
Hot Keys 13
I
Indicators 9
Intermittent Problems 119
internal mic and web camera 99
inverter board 96
J
Jumper and Connector Locations 121
Top View 121
K
Keyboard 36, 76
Keyboard or Auxiliary Input Device Check
102
L
Launch Board 84
LCD Bezel 94
Index

Acer Extensa 5220 Series Specifications

General

Display	15.4" WXGA (1280 x 800) TFT LCD
Optical Drive	DVD-Super Multi double-layer drive
Operating System	Windows Vista Home Basic
Processor	Intel Celeron M 530
RAM	512 MB DDR2
Storage	80 GB HDD
Graphics	Intel Graphics Media Accelerator (GMA) X3100
Battery	6-cell Li-ion
Weight	2.8 kg
Wireless	802.11b/g
LAN	10/100 Mbps Ethernet
Ports	3x USB 2.0, VGA, headphone/speaker/line-out jack, microphone-in jack
