Acer Extensa 5220 Series Service Guide

Chapter 1 35
Number of slots One type-II
Access location Left panel
Supports ZV (Zoomed Video) port No ZV support
Supports 32 bit CardBus Yes
System Board Major Chips
Item Controller
Core logic Mobile Intel® PM965/GM965/960 + ICH8M Express
Chipset
VGA ATI X2500, HD2400XT or HD2600
LAN Realtek 8100SBL/CL
USB 2.0 Intel ICH8M
Super I/O controller N/A
MODEM ALC 883
Bluetooth Built-in ATI SB460
Wireless 802.11 b+g Built-in ATI SB460
PCMCIA/ 5 in 1 Card Reader ENE CB714/1410
Audio Codec Realtek ALC883
Keyboard
Item Specification
Keyboard controller NS PC97541V
Total number of keypads 88-/89-key
Windows logo key Yes
Internal & external keyboard work
simultaneously
Plug USB keyboard to the USB port directly: Yes
Battery
Item Specification
Vendor & model name Panasonic (6cell) 2.0
Sanyo (6cell) 2.0
SMP (6cell) 2.0
Panasonic (8cell) 2.4
Sanyo (8cell) 2.4
SMP (8cell) 2.4
Battery Type Li-ion
Pack capacity 4000 mAH Panasonic (6cell) 2.0
4000 mAH Sanyo (6cell) 2.0
4000 mAH SMP (6cell) 2.0
4800 mAH Panasonic (8cell) 2.4
4800 mAH Sanyo (8cell) 2.4
4800 mAH SMP (8cell) 2.4
Number of battery cell 6/8
PCMCIA Port
Item Specification

Acer Extensa 5220 Series Specifications

General

Display	15.4" WXGA (1280 x 800) TFT LCD
Optical Drive	DVD-Super Multi double-layer drive
Operating System	Windows Vista Home Basic
Processor	Intel Celeron M 530
RAM	512 MB DDR2
Storage	80 GB HDD
Graphics	Intel Graphics Media Accelerator (GMA) X3100
Battery	6-cell Li-ion
Weight	2.8 kg
Wireless	802.11b/g
LAN	10/100 Mbps Ethernet
Ports	3x USB 2.0, VGA, headphone/speaker/line-out jack, microphone-in jack
