Chapter 3 67
2. Turn the base unit over, then remove the one screw (A) on the bottom side of the unit.
3. Carefully use a plastic screw driver (1) to eject the optical drive tray (2).
4. Pull the optical drive module out from the main unit.
Step Size (Quantity) Color Torque
1 M2.5 x L6 (1) Black 3.0 kgf-cm
To Next Page
