72 Chapter 3
3. Remove the nine screws (C) securing the CPU and VGA heatsink module in place.
NOTE: There are only five (5) screws for the UMA module.
4. Slide out and remove the heatsink module.
Step Size (Quantity) Color Torque
1~9 M2 x L4 (9) Silver 3.0 kgf-cm
