Acer PH530 - Remove each Side Cover

2-7
PH530Condential
No Procedure Photo
1 (1) Unplug 1 connector.
(as blue circle)
(2) Press 3 tennons on the
left.
(as green ellipse)
(3) Remove left side cover.
(4) Press 3 tennons on the
right.
(as green ellipse)
(5) Remove right side cover.
2-5 Remove Each Side Cover
