2-9
PH530Condential
2-7 Remove Side Shielding Module
No Procedure Photo
1 (1) Unscrew 3 screws.
(as red circle)
(2) Press 2 tennons.
(as green ellipse)
(3) Remove Side Shielding
Module.
ENGINE EMI THERMAL PLATE
