Acer PH530 - Chapter 1 Introduction; Highlight

1-1
PH530
Condential
Chapter 1
Introduction
1-1 Highlight
No Item Description
1 Weight Approx. 6.0 lbs
2 Dimension (W x D x H) - 284.1 x 239.0 x 92.2 mm
3 Cooling system - Air Tunnel Flow
- Cooling fans with optimized system acoustic noise
level
- Temperature control circuits with adaptive fan rotational
speeds
- High altitude cooling mode
- Maximum touch temperature follow UL60950
4 Lamp housing - Lamp Assembly could be changed by customer him
self, but should read the user manual for instruction in
advance.
- Lamp Assembly should be provided by Coretronic and
distributed through authorized agencies
5 Tilt angle - 6 degree with elevator mechanism
6 Power supply - Universal AC 100 – 240 V ~ 50-60 Hz with PFC input
- 200W Phoenix(SHP69) Lamp @ normal operation
- Variance FAN speed control (Depends on temperature
variant)
8 Power Consumption - Operation: TBD W +/-10% at 110Vac,
Standby < TBD W
9 Input signal spec. - Hsync Frequency 31.5 ~ 100 kHz
- Vsync Frequency 56 ~ 85 Hz
- Video Signal RGB (PC)
- Analog RGB 0.7Vp-p, 75 ohm, Separate TTL H,V Sync
- Analog RGB 1Vp-p, 75 ohm, Sync. On Green signal
- Analog RGB 0.7Vp-p, 75 ohm, Composite TTL Sync.
- Video
- Composite video 1Vp-p,75 ohm
- S-video Luminance 0.714Vp-p, 75 ohm
- Chrominance 0.286Vp-p, 75 ohm
- Component video 1Vp-p, 75 ohm
