2-21 Remove Lens Support and Interrupter Switch
No Procedure Photo
1 (1) Unscrew 1 screw.
(as red circle)
(2) Remove Lens Support.
(3) Unscrew 2 screws.
(as red circle)
(4) Remove Interrupter
Switch.
