29
Both Ignitors must be enabled for this option to
have an effect on the Alarm/Status contacts
°
C Difference Shutdown Y/N
Yes: Shutdown if TC1 & 2 are different by greater
than 10°C (18°F)
No: No link between TC1 & TC2
4-20mA Output Settings Menu
4-20mA Input 1 Settings Menu (Level)
4-20mA Input 2 Settings Menu (Press.)
Purge Cycle Time (0s - 300s) (before first ignition
trial)
Extra Inter-Purge Time (0s - 240s) between
Ignitor relight trials.
Power Save Enable/Disable
Power Fail Shutdown Latched/Unlatched
High Temp Shutdown Latched/Unlatched
TC3 High Temp SD Latched/Unlatched
High Gas Shutdown Latched/Unlatched
Low Gas Shutdown Latched/Unlatched
Level Shutdown Latched/Unlatched
Auxiliary 1 Shutdown Latched/Unlatched
Auxiliary 2 Shutdown Latched/Unlatched
Config
Line Display Configuration - Select items to
display on the three top lines on the display
Line 1: TC1 temp w setpoint
Select information to display for Line 1
Line 2: TC2 temp w setpoint
Select information to display for Line 2
Select information to display for Line 3
Change TC1 Ignitor 1 Setpoint temperature
°
Change TC1 Ignitor 2 Setpoint temperature
°
Change TC2 Setpoint temperature
TC3 Set 400°C
Change TC3 Setpoint temperature
Change Low Temp SD/ALM Setpoint temperature
Set Deadband for TC1 IGN1: 1-5
°
°
Set Deadband for TC1 IGN2: 1-5°C or 2-10°F
Set Deadband for TC2: 1-5°C or 2-10°F
Set Deadband for TC3: 1-5°C or 2-10°F
SD
Show the last shutdown(s) for IGN 1 / 2 and the
time and date that they occurred
Display time that the TMain 1 solenoid has been
on since the last TMain timer reset
Reset TMain 1 solenoid timers
Time View
Display time that the TMain 2 solenoid has been
on since the last TMain timer reset
To Next Page
