ACL CSC400 User Manual

30
Days
Information
Reset TMain 2 Timers
Option
Reset TMain 2 solenoid timers
2.7
Solenoid Drivers
Menu
Low Power Solenoid Driver settings
Pilot 1 100
Option
Duty Cycle time for Pilot 1 solenoid output
Main 1 100
Option
Duty Cycle time for Main 1 solenoid output
TMain 1 100
Option
Duty Cycle time for TMain 1 solenoid output
Pilot 2 100
Option
Duty Cycle time for Pilot 2 solenoid output
Main 2 100
Option
Duty Cycle time for Main 2 solenoid output
TMain 2 100
Option
Duty Cycle time for TMain 2 solenoid output
2.8
Time Set
Menu
Hours
Option
Hour for the current time
Minutes
Option
Minutes for the current time
12/24 Hour Time
Option
Select between 12 or 24 hour time display
2.9
Date Set
Menu
Day
Option
Current day
Month
Option
Current month
Year
Option
Current year
2.10
Modbus Settings
Menu
Slave ID
Option
Modbus Slave ID of the CSC400
Baud Rate
Option
Serial Baud rate for Modbus RTU
Format
Option
Serial Format for the CSC400 (eg. "8N1": 8 bits,
No parity bits, 1 stop bit)
TLog Rate
Option
Period for logging temperatures into Temp Logs
for reading via modbus
2.11
Diagnostics
Information
Shows firmware version and diagnostics
information
2.12
Reset SD Log
Menu
Reset SDLog to Default
Reset (clear) all stored Shutdown Log entries:
(Yes, No/Cancel)
2.13
Reset TLog
Menu
Reset T Logs to Default
Reset (clear) all stored Temperature Log entries:
(Yes, No/Cancel)
2.14
Reset Settings
Menu
Reset Settings to Default
Reset all CSC400 settings to the defaults: (Yes,
No/Cancel)
2.15
Recalibrate TC
Menu
Recalibrate Thermocouple
inputs
Recalibrate Thermocouple inputs (Yes,
No/Cancel)
Configuration
Submenus:
2.1.14
4-20 Out
Settings
Menu
4-20mA Output Settings Menu
4-20 Out 1 Temp TC1
Option
4-20mA Output 1 Mode Select
Low ( 4) -60
°
C
Option
4-20mA Output 1 Low value for 4mA
High(20) 1200°C
Option
4-20mA Output 1 High value for 20mA
