Isolated 4-20 mA Signal
Splitters & Converters
Acromag Inc offers DIN rail mountable signal splitters
and converters to spit the optional 4-20 mA signal into
two isolated 4-20 mA signals or into a 0-10 VDC signal.
Isolated 4-20 mA Signal Splitter
The Vertu’s optional 4-20 mA output can be split into
two isolated 4-20 mA signals by using the model
SP336-7000 4-20 mA signal splitter.
Figure 28. Passive 4-20 mA Output from Vertu Meter
Split into Two Isolated 4-20 mA Signals
4-20 mA to 0-10 VDC Signal
Converter
The Vertu’s optional 4-20 mA output can be converted
into a 0-10 VDC signal by using the model
TT336-0700 4-20 mA to 0-10 VDC signal converter.
Figure 29. Passive 4-20 mA Output from Vertu Meter
Converted to 0-10 VDC Signal
