Acromag Vertu Series User Manual

Vertu Series VPM3000 Process Meters & Temperature Transmitters
Instruction Manual
43
Quick Interface Reference Guide
Run Mode
Setup
Password
Display
Max/Min
Input
4-20 mA
0-10 V
RTD
TC
Decimal
Point
dddd
d . ddd
dd . dd
ddd . d
A385
A392
Type J
Type K
Type T
Type T.0
Type E
F
C
F or C
To Program
Locked Unlocked
TC or RTD?
Yes No
Relays
Relay 1
Relay 2
Failsafe
Delays
Action
Set point
Reset point
Auto
Auto & Manual
Latch
Latch w/Clear
Pump Alt
Off
To
Set point
Failsafe 1
Failsafe 2
To Delays
Delay 1
Delay 2
On
Off
Analog
output
Scale
Sensor
break
To Password
RTD or Type T
No Yes
Calibrate
Scale
TC or RTD?
Yes No
Program
To Relays
