• Two User Limits A & B may be configured. These can be used to generate outputs when
the number of users in the area reaches a certain level. This may be used for certain
security critical areas. In addition an output may be configured to operate when any users
are present within the area. This could be used to switch on or off certain equipment when
the area is empty. The larger of the two limits is also used to determine how many tracked
users to admit into the anti-passback area. Once this limit is reached, access is denied to
other tracked users. This could be used in a car-park application. User Limiting must be
enabled for this to operate (see System Settings > Operation).
Outputs
The ACTpro 4000 has 6 onboard outputs that can operate in addition to the local relay. These
are the open collector outputs OP2 and OP3 (for doors 1 and 2) as well as the two auxiliary
1A relays. Normally these outputs perform the same functions as other doors, according to
the programmed user and/or door settings. However the onboard outputs on the ACTpro
4000 may be given alternate functions as outlined below.
AUX
AUX Any Door
Auxiliary relay activates when any auxiliary relay is activated
for any door on the controller.
OP2
Tech Fault
Open collector output OP2 activates when a technical fault
condition exists (tamper/mains fail/door offline).
Door 1
OP3
Any Door Open
Open collector output OP3 activates when any door on the
controller is open.
AUX
Users Present
Auxiliary relay activates when one or more users are logged
in to the tracking area.
OP2
User Limit A
Open collector output OP2 deactivates when the number of
users in a tracking area is at or above User Limit A.
Door 2
OP3
User Limit B
Open collector output OP3 deactivates when the number of
users in a tracking area is at or above User Limit B.
Door Settings
The Door Settings menu allows the installer to access a number of different configuration
menus controlling different aspects of the selected door. The door for which the settings are
to be changed is first selected using the 0 key and then the  key is pressed to enter the
menu.
The 0 key is used to select the required option or setting which is changed using the  key.
Operation
This menu allows the installer to select or de-select a number of options relating to the default
operation of the door.
