2.4. IDENTIFICATION TAGS
The identication tags on the tubehead, on the timer and on the cone indicate the model number, the serial
number, the manufacturing date and the symbols of the main technical characteristics.
2.3.1. TUBEHEAD
Model 230 V
Model: x-mind ac
®
de Götzen S.r.l.
®
Via Roma 45 - 21057 Olgiate Olona (VA) - ITALY
70kVp 8mA
230V ~ 50/60Hz
TOSHIBA DG-073B-AC
Rated line voltage:
X-ray tub e:
Total filtratio n: 2,3mm Al / 70kV 0.7mm
Class I
tube:
SN SN
Model 220 V
Model: x-mind ac
®
de Götzen S.r.l.
®
Via Roma 45 - 21057 Olgiate Olona (VA) - ITALY
70kVp 8mA
220V ~ 50/60Hz
TOSHIBA DG-073B-AC
Rated line voltage:
X-ray t ub e:
Total filtratio n: 2,3mm Al / 70kV 0.7mm
Class I
tube:
SN SN
Model 115 V
Model: x-mind ac
®
de Götzen S.r.l.
®
Via Roma 45 - 21057 Olgiate Olona (VA) - ITALY
70kVp 8mA
115V ~ 50/60Hz
TOSHIBA DG-073B-AC
Rated line voltage:
X-ray tube:
Total filtration: 2,3mm Al / 70kV 0.7mm
Class I
tube:
SN SN
2.3.2. TIMER
Model 230 V
Model: x-mind ac
®
de Götzen S.r.l.
®
Via Roma 45 - 21057 Olgiate Olona (VA) – ITALY
Rated line voltage:
Absorbed power:
230V 50/60Hz Class I
0,8kVA IP20
~
SN
