Chart B
MANUFACTURER’S RATING PLATE
220 V ± 10%
230 V ± 10%
115 V ± 10%
POWER SUPPLY VOLTAGE 198 ≤ V ≤ 253 103,5 ≤ V ≤ 126,5
MINIMUM CONDUCTOR SECTION
MAXIMUM LINE LENGHT
1,5 mm2
10 m
MAXIMUM CONDUCTOR SECTION
MAXIMUM LINE LEGHT
2,5 mm2
20 m
PLEASE NOTE
For longer lines, the conductor section must be increased in proportion.
- The cables (S11, S12 – S21, S22) connecting the timer and the X-ray signalling lamp for external use must be
two-pole type, of section 0,5mm2.
- The electric line characteristics must have the following characteristics (Chart C):
Chart C
MANUFACTURER’S RATING PLATE
ELECTRICAL LINE
220 V ± 10%
230 V ± 10%
115 V ± 10%
MAXIMUM VOLTAGE DROP 3 %
APPARENT LINE RESISTANCE 0,5 Ω 0,2 Ω
ELECTRIC CONNECTIONS
!
WARNING
Prior to installing the radiographic system, it is advisable that all the electric connections are arranged.
TIMER
On the timer installation wall, according to the installation electric diagram (refer to Chapter 15), suitable runs for
the following electric cables must be provided:
} timer electric cables;
} cables for the connection between timer and tubehead;
} cables for the connection between the timer and the X-ray signalling lamp for external use x-mind ac® LIGHT
(OPTIONAL);
} cables for the connection between the timer and the remote control button x-mind ac® ECB (OPTIONAL).
CAUTION
According to the relevant standard, the timer must be installed in a position that allows the operator to constantly control the radiographic
exposure.
TUBEHEAD
On the wall plate installation wall, a suitable run for the cable connecting timer and tubehead must be provided.
