75
ENGLISH
INSTALLATION & MAINTENANCE MANUAL • X-MIND AC • V2 • (06) • 08/2016 • NXACEN020B
ANNEX 6
A6. DRAWINGS AND DIMENSIONS
WALL INSTALLATION
Lateral view (rest position)
Bottom mount
A
40 cm (16’’) bracket 63 cm
80 cm (31’’) bracket 104 cm
110 cm (43’’) bracket 132 cm
