ENGLISH
INSTALLATION & MAINTENANCE MANUAL • X-MIND AC • V2 • (06) • 08/2016 • NXACEN020B
REF SPARE PARTS TIMER x-mind ac®
CODE
(RAL 9010 color)
OLD COLOR Q.TY PCS
1 AC/DC TIMER (1) DRILL TEMPLATE 24200883 1
2 AC7DC XG TIMER (2) CONTROL BOARD 39200306 7
2 AC/DC XG TIMER (2) CONTROL BOARD US 39200307 7
3 AC/DC XG TIMER (3) SPIRAL CABLE 32000325.C 32000325 1
KIT SPIRAL CABLE + LOCAL BUTTON 29701028.C COMPLETE
4
AC/DC XG TIMER (4) DOUBLE LENGHT
SPIRAL CABLE
32000359 1
KIT DOUBLE LENGHT SPIRAL CABLE +
EXPOSURE BUTTON
29701029.C COMPLETE
5
AC/DC XG TIMER (5) EXPOSURE BUTTON
CASE
29700974.C 4
6
AC/DC XG TIMER (6) ESPOURE BUTTON
BOARD
39700303 1
7 AC/DC XG TIMER (7) LED BOARD 39200313 7
8 AC/DC XG TIMER (8) KEYBOARD DEG 39200510 39200308 1
8 AC/DC XG TIMER (8) KEYBOARD SAT 39200309 1
9 AC/DC XG TIMER (9) BOTTOM TIMER CASE 29700975.C 29700975 1
10
AC/DC XG TIMER (10) TOP TIMER CASE
DEG
29700304.C 29700304 4
10 AC/DC XG TIMER (10) TOP TIMER CASE SAT 29700976.C 29700976 4
11 AC/DC XG TIMER (11) SECURITY KEY SET 39700305 2
12 DC XG TIMER (12) EMI FILTER 36200382 3
13 BIPOLAR GREEN SWITCH 35000044 1
14 BIPOLAR SWITCH COVER 33500228 1
