Actron AutoTroubleShooter User Manual

35
Electrical Specifications
DC Volts
Range: 200mV, 2V, 20V, 200V
Accuracy : ±(0.5% rdg + 5 dgts)
Range: 600V
Accuracy: ±(0.8% rdg + 5 dgts)
AC Volts
Range: 2V, 20V, 200V
Accuracy : ±(0.8% rdg + 5 dgts)
Range: 600V
Accuracy: ±(1.0% rdg + 4 dgts)
DC Current
Range: 200mA
Accuracy: ±(0.8% rdg + 5 dgts)
Range: 10A
Accuracy: ±(1.2% rdg + 5 dgts)
Resistance
Range: 200Ω, 2KΩ, 20KΩ, 200KΩ, 2MΩ
Accuracy: ±(0.8% rdg + 5 dgts)
Range: 20MΩ
Accuracy: ±(1.5% rdg + 5 dgts)
Dwell
Range: 4CYL, 6CYL, 8CYL
Accuracy: ±(3.0% rdg + 5 dgts)
RPM
Range: 4CYL, 6CYL, 8CYL
Accuracy: ±(3.0% rdg + 5 dgts)
Audible Continuity
Buzzer sounds at approximately less
than 30-50 Ohms.
Operating Temperature:
32°F~104°F (0°C~40°C)
Relative Humidity:
0°C~30°C <75%, 31°C~40°C<50%
Storage Temperature:
14°F~122°F (-10°C~50°C)
Barometric Pressure: 75 to 106 kPa.
The Meter is only for indoor use.
Safety Class: CAT III 600V, Pollution
degree 2
Display Count: 1999
Altitude: ≤2000m
Battery: 9V (NEDA 1604,6F22 or
006P)
Dimension: 6.81" x 3.11" x 1.58" (173
x 79 x 40 mm)
Weight: 8.04 oz. (228 g) excluding
battery
For technical assistance,
Please contact:
Actron Tech Service
Bosch Automotive Service Solutions
655 Eisenhower Dr.
Owatonna, MN 55060
USA
Phone: 800-228-7667
Fax: 800-955-8329
