200S 61
II - 5 Remote Switch Data Output
Example 5: Probing function Centerline
Coordinate of centerline on X axis CLX = + 3476.9963 mm (Center
Line X axis)
Distance between the probed edges DST = 2853.0012 mm (Distance)
1 Colon
2 +/– sign, or Blank Space
3 2 to 7 places before the decimal point
4 Decimal point
5 1 to 6 places after the decimal point
6 Unit: blank space for mm, “ for inches
7R for Radius, D for Diameter display
8 Carriage return
9 Blank line (Line Feed)
CLX
:+3 4 7 6 . 9 9 6 3 R <CR> <LF>
DST
: 2 8 5 3 . 0 0 1 2 R <CR> <LF>
12345678 9
