Technical Specifications
Maximum Operating Pressure
District Heating 6 bar
Primary 3 bar
Secondary 10 bar
Factory Test Pressure
District Heating 9 bar
Primary 4.5 bar
Secondary 13 bar
Maximum Operating Temperature
90°C
Langdon Hills,Basildon,Essex.
This refurbishment of the heating and hot water systems for Basildon District Council of a 1960’s housing estate
utilised the existing district heating mains infrastructure together with a selection of 278 SVM TripleTanks.
The design was undertaken by G K Salter & Associates of Swanley, Kent.The installation was carried out by
Interserve FM Ltd.
Project References
Hillside Towers,Sheffield.
These apartment blocks were the first in the UK to make use of the superior characteristics of the ACV SVM
TripleTanks in District Heating.This Sheffield City Council financed refurbishment involved the total renovation of
seven 1960’s-built blocks of flats,which involved the installation of 336 SVM 115 TripleTanks.The design was
undertaken by DBS Architects of Sheffield and installed by local contractor Bumford Heating Ltd of Barnsley.
SVM SVM SVM
115 140 180
Code 06223901 06221801 06224101
Total capacity L 149 182 208
Primary (district heating) capacity L 26 30 33
Intermediary (central heating) capacity L 17 20 22
DHW capacity L 106 132 153
Primary heating surface area m
2
1.67 1.99 2.23
Typical output to central heating kW 15.7 17.4 20.5
DHW heating surface area m
2
1.4 1.71 2.0
Primary connections (female BSP) Ø
3
/
4
”
3
/
4
”
3
/
4
”
Intermediary connections (male BSP) Ø
3
/
4
”
3
/
4
”
3
/
4
”
DHW connections (male BSP) Ø
3
/
4
”
3
/
4
”
3
/
4
”
Dimensions height mm 1450 1700 1880
width mm 475 475 475
depth mm 500 500 500
Weight empty Kg 110 130 148
Weight full Kg 259 312 356
