ACV 2004 User Manual

Concentric Flue Systems
47
Concentric Flue Systems
A
F
B
D
C
E
TERMINALS
A
Code Type
537d6196 Vertical terminal
537d6173 Horizontal terminal
FLUE PIPE
B
Code Type
537d6174 Length 250 mm
537d6175 Length 500 mm
537d6176 Length 1000 mm
ADJUSTABLE FLUE PIPE
C
Code Type
537d6177 500 mm adjustable
length 325-400
FLUE BENDS
D
Code Type
537d6178 Bend 43°- 45°
537d6179 Bend 87°- 90°
CONDENSATE RECOVERY AND GAS ANALYSER CONNECTOR
E
Code Type
537d6180 Gas analyser with
condensate recovery
FLASHINGS AND BRACKETS
F
Code Type
537d6181 Flat roof flashing
537d6182 Adjustable flashing
537d6183 Bracket 125 mm
Prestige 24 - 32
Delta Performance FV/MV 35
STEEL - STAINLESS STEEL Ø 80/125
