ACV 2004 User Manual

Electric Combined Boilers & Water Heaters
31
Product Description
E-Tech S
• Electric combined boiler and water heater
• Power input modulation variable in accordance
with heat demand
• Stainless steel Tank-in-Tank design
• Can also be used as a stand-alone water heater
• Very easy to maintain
• Anti-Legionellae :hot water stored at consistently
high temperature
• Fully insulated with 70mm rigid polyurethane foam
for minimal heat loss
• Stove enamelled casing
• Control panel including thermostats,
combined
temperature and pressure gauge
,
indicators and on/off switch
• Up to 14.4 kW output in single phase,up to
28.8kW tri-phase
• Vented or unvented use,with mains pressure
SystemPaks available
• Integral primary heating sealed system kit and
circulating pump
• Small footprint enabling compact installation
1. Domestic water and
temperature and pressure
relief valve connections
2. Primary water flow connection
3. Expansion vessel
4. Stainless steel inner tank
5. Primary drain connection
6. Heating elements
7. Control thermostat pocket
8. Primary water return
connection
9. Primary heating circuit
10. Primary safety valve
11. Primary low water pressure
switch
12. Rigid polyurethane foam
insulation
10
11
9
4
7
8
3
6
5
2
1
12
Flexible Installation Options
The E-Tech S has three
connections for heating
flow and return,which
allows a choice of
installation positions and
means that the E-Tech S
can be installed in a corner
and against a wall without
the need to allow free
space around the unit.
All hot and cold water
connections can be fitted
under the removable top
panel,again saving space
and resulting in a very tidy
installation.
E-Tech S
