ACV has developed this burner specially for the HeatMaster 60.
One of the BG 2000-S air/gas premix burner range,it has a metal
fibre (NIT) flame tube and smooth and near-silent ignition and
operation.It is ideal for use in applications where burner noise
must be kept to a minimum.Factory set for natural gas,and
includes a simple conversion kit for LPG use.
Combined Boilers & Water Heaters
21
Product Description
HeatMaster® 60
1. Stainless steel inner tank
2. Primary heating circuit
3. Flue pipes with stainless
steel turbulators
4. Rigid polyurethane
foam insulation
5. Primary shunt pump
6. Combustion chamber
7. Oil or gas burner
8. Control panel
9. Primary water flow
connection
10. Primary water return
connection
11. Domestic cold water inlet
12. Domestic hot water outlet
8
1
5
7
11
12
9
3
4
2
10
6
BG2000-S/60 burner
• High performance combined boiler and water heater
• Stainless steel Tank-in-Tank design
• Choice of burner :
- Low NOx premix gas or LPG (BG2000-S)
- Pressure jet natural gas or LPG (Riello)
- Pressure jet 28 sec or 35 sec oil (Riello)
• Can also be used as a stand-alone water heater
• Anti-Legionellae :hot water stored at a consistently
high temperature
• Built-in primary circuit shunt pump
• Fully insulated with rigid polyurethane foam
• Stove enamelled casing
• Control panel including thermostats,combined
temperature and pressure gauge,indicators
and on/off switch
• Available with balanced flue (BG2000-S burner only)
• 63 kW output and up to 1106 litres of hot water
at 60
º
C in one hour
• Vented or unvented use,with mains pressure
SystemPaks available
HeatMaster® 60
