Select CH Demand
Thermostat & Outd. Curve
Constant & Outdoor Curve
Constant & Setpoint
0 - 10 V Modulation Signal
CH1 Setpoint
82°C
20°C 87°C
CH2 Setpoint
60°C
20°C 87°C
EZ Setup Complete
Heating EZ setup is complete.
Additional changes can be made in
the Installer Menu if required.
Press OK to return to EZ Setup Menu
EZ Setup Complete
Heating EZ setup is complete.
Additional changes can be made in
the Installer Menu if required.
Press OK to return to EZ Setup Menu
Select CH Demand
Thermostat & Outd. Curve
Constant & Outdoor Curve
Constant & Setpoint
0 - 10 V Modulation Signal
Refer to page 9 for screen descriptions
Refer to page 9 for screen descriptions
EZ Setup
Heating EZ Setup
Warm Weather Shutdown
O
O 25°C
