8230 Optical Power Meter Operation Manual
8. SPECIFICATIONS
8-1
8. SPECIFICATIONS
8.1 8230 Specifications
All accuracies are guaranteed for one year at a temperature of +23 C 5 C and a relative humidity of 70%
or less.
8.1.1 Instrument Specifications
Item Specification
Display resolution 0.1 pW (W is displayed), 0.001 dB (dBm is displayed)
Accuracy The following is added to the accuracy of each sensor. (Within 24 hours
after the offset zero is executed, unit: W, display: 5-1/2 digits, and CF = 1)
20 nW range: (0.55% + 2000 digits)
200 nW range: (0.15% +200 digits)
2 W to 200 mW range: (0% +70 digits)
Display LCD with three-level backlight
Wavelength display: 4 digits
Power display: 5-1/2 digits (Unit; mW, W, nW, dBm, and dBr)
Bar graph display
Range switching 8 ranges: Automatic, manual, and remote
Measurement speed Display: 5 times/second or more, Remote: 9 times/second (Hold/Trigger)
Compatible optical sensor 823x series: 82311B/82312B/82313B/82321B/82322B/82323B/
82314B/82314BW/82324B
82311/82312/82313/82321/82322/82323
( 82314A/82314W/82324A )*2
821x series: 82014A/82017A (82015/Q82018A *1) *3
Wavelength sensitivity correction Automatically corrects the sensor wavelength sensitivity by setting wave-
length (in 1 nm steps)
For the 823x series optical sensor, each value stored in the sensor is used
as the wavelength sensitivity correction value.
(Sensor-specific data for the 82311/82311B option 20 and 82321/82321B
option 20, or the typical values for the 82311/82311B and 82321/82321B
standard models are stored.)
For the 821x series optical sensor, the typical value stored in the optical
power meter is used. *3
Calibration wavelength selection
function
This function operates when the calibration wavelength addition option is
included in the sensor.
Wavelength preset function Four wavelengths where wavelength sensitivity correction is performed
can be registered. (This function can be used only from the operation
panel.)
Smoothing function Moving average from 2 to 100 times
To Next Page
