ADCMT 823B Series User Manual

8230 Optical Power Meter Operation Manual
6.2 Performance Test for Optical Sensors
6-5
6.2 Performance Test for Optical Sensors
To calibrate the optical sensors, the light source, optical fiber, standard optical power meter, all of which meet
the specifications described below, as well as a measuring environment with little or no vibration, at a tem-
perature of +23 C  5 C, and a temperature change of 1 C are required.
Table 6-4 Equipment Required for Evaluating Optical Sensors
Product
Light source
Fiber FC adaptor
Wavelength Output Stability
82311B 780 nm 1 mW 0.20% PMF/SMF or GI50m WBL-Q17ADAPTER
82312B 405 nm 1 mW 0.20% PMF/SMF WBL-Q82312ADAPTER
82313B 650 nm 1 mW 0.20% PMF/SMF WBL-Q82313ADAPTER
82321B 780 nm 1 mW 0.20% PMF/SMF or GI50m A08012
82322B 405 nm 1 mW 0.20% PMF/SMF A08012
82323B 650 nm 1 mW 0.20% PMF/SMF A08012
82314B 405 nm 1 mW 0.20% PMF/SMF WBL-Q82312ADAPTER
82314BW 405 nm 1 mW 0.20% PMF/SMF WBL-82314WADAPTER
82324B 405 nm 1 mW 0.20% PMF/SMF A08012
8230/8250A For connecting a sensor
Optical power meter Standard Must be calibrated at an accuracy of 0.8% or less
for each wavelength.
To evaluate the optical sensor at the additional calibration wavelength, prepare the corresponding light sources
and fibers.
