Adept Lynx Platform User's Guide, Rev D
Page 26 of 126
Chapter 2: Setup
Refer to Removing and Installing Covers in the Maintenance section for cover removal and
installation.
1.
Remove the inner rear platform cover.
a.
Pull the bottom of the cover away from the platform chassis.
This is easiest if you grip it with two hands, toward the center.
b.
Lower the cover down, so its top tab clears the rear outer cover.
2.
Unlatch and open the battery compartment door, at the back of the platform.
The battery compartment door is capable of being locked. You may need to unlock it.
